PRODUCT PARAMETERS
At rated frequency, the rotation speed is not affected by voltage. If overload or stall when loaded, the motor coil will not burn. There are three options of rotation direction to choose from: CW, CCW and CW/CCW.
Note：
If you choose the rotation direction CW/CCW and apply load over rated torque, the rotation direction will automatically reverse.
If you choose the rotation direction CW or CCW, the motor will not change its rotation direction.
Note：
This motor is AC Synchronous motor. The rotation speed is only related with frequency.
Please see the parameter table, for example you choose the rotation speed = 2 rpm.
If your country's frequency is 50Hz, the rotation speed is 2 rpm.
If your country's frequency is 60Hz, the rotation speed is 2*1.2= 2.4 rpm.
We can customize various shafts, speed, torque, wire, lead, etc. according to your requirements. Please send an inquiry or TM to tell us. Please leave a message to tell us your choice of voltage, rotation direction (CW, CCW and CW/CCW) to get quick quotation.
For example：
220V 50Hz, 2RPM, Torque＞16kgf.cm，CW, wire length=50cm
PRODUCT APPLICATIONS
At rated frequency, the rotation speed is not affected by voltage. If overload or stall when loaded, the motor coil will not burn. There are three options of rotation direction to choose from: CW, CCW and CW/CCW.
